Frame
Prime Xtralite 6061 Fully Butted Alloy, Forward Geometry, internal non-removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor

Sizes
XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm

Fork
RockShox 35 Silver TK 29, 120mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips
Onoff Twin, 1lock-on, 135mm

Seatpost
Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm

Saddle
MDK ebike black

Front brake
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Rear brake
Sram DB8, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

Brake lever
Sram DB8, tool reach adjust

Rims
MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

Spokes
CN round stainless steel

Front hub
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

Rear hub
Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

Front tire
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Rear tire
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Crankset
Race Face Aeffect ebike, 165mm

Rings
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Chain
Sram SX Eagle, 12s, Powerlock

Rear derrailleur
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Casette
Sram PG-1210, 11-50T, 12s

Derailleur hanger
Mondraker M068

Weight
23,3 kg

Display
Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller

Motor
Bosch Performance Line CX (25km/h) Smart System

Battery
Bosch Powertube 750Wh
