Frame
Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.


Sizes
S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Rear shock
Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings


Shock settings
medium compression, medium rebound, air volume spacer 0.2

Fork
Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload


Headset
Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing

Stem
Onoff Krypton FG 30mm, CNC, 31.8mm barbore


Handlebar
Onoff Krypton 1.0 double butted 7075-T6 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips
Onoff Desert, 1lock-on, 135mm


Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm

Saddle
FIZIK Terra Aidon X5 145mm


Front brake
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

Rear brake
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads


Brake lever
Sram DB8, tool reach adjust, lever pivot bushings

Rims
Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes


Spokes
Mavic J-bend double butted, contactless lacing

Front hub
Mavic, Boost 15x110mm, IS 6 bolts


Rear hub
Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub

Front tire
Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead


Rear tire
Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Crankset
Race Face Aeffect ebike, 165mm


Rings
Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD

Chain
Sram NX Eagle, 12s, Powerlock


Rear derrailleur
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Shift levers
Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click


Casette
Sram PG-1230, 11-50T, 12s

Derailleur hanger
Sram UDH


Weight
24,2 kg

Display
Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller


Motor
Bosch Performance Line CX Cruise (25 km/h) GEN4 SMART SYSTEM
