Frame
Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.



Sizes
S: 380mm / M: 420mm / L: 450mm / XL: 490mm

Rear shock
Fox Float-X LV Factory Kashima, 205x65mm. Settings: compression 2 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings



Shock settings
medium compression, medium rebound, air volume spacer 0.2

Fork
Fox 38 29 Float GRIP2 Factory Kashima, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high and low-speed compression, high and low-speed rebound, air preload


Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore


Handlebar
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips
Onoff Desert, 1lock-on, 135mm


Seatpost
Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L/XL size: 475.1x175mm

Saddle
FIZIK Terra Aidon X5 145mm


Front brake
Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Rear brake
Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads



Brake lever
Sram Code R, tool-free reach adjust

Rims
Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes



Spokes
Mavic J-bend double butted, contactless lacing

Front hub
Mavic, Boost 15x110mm, IS 6 bolts


Rear hub
Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts

Front tire
Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead


Rear tire
Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

Crankset
Race Face Aeffect ebike, 165mm


Rings
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

Chain
Sram NX Eagle, 12s, Powerlock



Rear derrailleur
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

Shift levers
Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click


Casette
Sram XG-1230, 11-50T, 12s

Derailleur hanger
Mondraker M068

Weight
25,5 kg

Display
Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller



Motor
Bosch Performance Line CX (25km/h) Smart System
