Frame

Carbon HMX
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline

Travel

Front: 130mm / Rear: 130mm

Fork

FOX 34 Float Factory Air / Kashima FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle / 44mm offset
Tapered steerer / Lockout / Reb. Adj.
130mm travel

Rear Shock

FOX NUDE 5T Factory EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Kashima / Reb. Adj.
Travel 130-90-Lockout / T165X45mm

Remote System

SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes

Drive Unit

TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph

Battery

TQ Internal 360Wh + Range Extender 160Wh

Display

TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app

Charger

TQ 100-240V-4A

Rear Derailleur

SRAM XX Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System

Shifters

SRAM AXS Pod Ultimate Controller

Crankset

FSA Carbon crankset / 175mm / 34T

Chainguide

e*thirteen / e*spec Slider

Chainring

Scott custom spider / SRAM Eagle Transmission 34T chainring

Chain

SRAM CN XX Eagle Transmission

Cassette

SRAM XX Eagle XS 1297 Transmission 10-52

Brakes

Shimano XTR M9120 4 Piston Disc

Rotor

Front: RT-MT900 CL 180mm / Rear: RT-EM910 CL 180mm

Handlebar

Syncros Fraser iC SL DC Carbon
0° rise / back sweep 8° / mini Rise / 760mm
Syncros Performance XC lock-on grips

Seatpost

FOX Transfer Factory Dropper Post Kashima
31.6mm / S size 125mm / M size 140mm
L ize 150mm / XL size 175mm

Seat

Syncros Tofino Regular 1.0
Carbon rails

Headset

Syncros - Acros Angle adjust & Cable Routing HS System
Stainless
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

Wheelset

Syncros Silverton SL2-30 CL full Carbon
F: 15x110mm
R: 12x148mm / 30mm Tubeless ready rim
DT Swiss 240 Ratchet EXP 36 / XD Driver
SRAM TyreWiz / Syncros SL Axle w/Removable Lever
with 6mm Allen
T30 and T25 Tools

Front Tire

Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft

Rear Tire

Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip

Extras

SRAM AXS Powerpack
Syncros Fork Fender

Accessories

Syncros Eco Sealant
Transport Axle

Approx weight in KG

15.5 (Tubeless setup)

Max. System Weight

110 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
