Frame

Carbon HMX
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline

Travel

Front: 130mm / Rear: 130mm

Fork

FOX 34 Float Performance Elite Air FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout
130mm travel

Rear Shock

FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 130-90-Lockout / T165X45mm

Remote System

SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes

Drive Unit

TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph

Battery

TQ Internal 360Wh

Display

TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app

Charger

TQ 100-240V-4A

Rear Derailleur

SRAM GX Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System

Shifters

SRAM GX Eagle AXS Rocker Controller

Crankset

FSA Carbon crankset / 175mm / 34T

Chainguide

e*thirteen / e*spec Slider

Chainring

Scott custom spider / SRAM Eagle Transmission 34T chainring

Chain

SRAM CN GX Eagle Transmission

Cassette

SRAM GX Eagle XS 1275 Transmission 10-52

Brakes

Shimano XT / BR-M8120 4 Piston

Rotor

Front: RT-MT800 CL 180mm / Rear: RT-EM810 CL 180mm

Handlebar

Syncros Fraser iC SL DC Carbon
0° rise / back sweep 8° / mini Rise / 760mm
Syncros Performance XC lock-on grips

Seatpost

FOX Transfer Dropper Post
31.6mm / S size 125mm / M size 140mm
L size 150mm / XL size 175mm

Seat

Syncros Tofino 1.5 Regular
Titanium rails

Headset

Syncros - Acros Angle adjust & Cable Routing HS System
Stainless
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

Wheelset

Syncros Silverton 1.5-30 CL
F: 15x110mm
R: 12x148mm
30mm Tubeless ready rim 28H / XD Driver
Syncros Axle w/Removable Lever
with 6mm Allen
T30 and T25 Tools

Front Tire

Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft

Rear Tire

Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip

Extras

SRAM AXS Powerpack
Syncros Fork Fender

Accessories

Syncros Eco Sealant
Transport Axle

Approx weight in KG

16.3 (Tubeless setup)

Max. System Weight

128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
