FRAME

Alloy Frame & Link
Virtual 4 link kinematic VLK
29x2.6 / Boost 148x12mm UDH
150mm travel / Bosch Gen4 / Integr. removable Battery
1.8" Headtube, Central Kickstand Mount
Integr. Cable

TRAVEL

Front & Rear: 150mm

FORK

RockShox 35 TK Air
15x110mm QR axle / 1.8" Tapered Steerer
Reb. Adj. / 2 Modes / Lockout / 150mm travel / E-Bike

REAR SHOCK

X-Fusion NUDE eRIDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 150-100-Lockout / 205x55mm

REMOTE SYSTEM

SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes

DRIVE UNIT

Bosch Performance CX
EU: 25kmh / INT: 20mph

BATTERY

PowerTube 625Wh

DISPLAY

Bosch LED Remote & Kiox 300

CHARGER

4A Charger

REAR DERAILLEUR

SRAM NX Eagle / 12 Speed

SHIFTERS

SRAM SX Eagle Single Click

CRANKSET

FSA CK-745 / 165mm / 34T

CHAINGUIDE

e*thirteen / e*spec Slider

CHAINRING

SRAM Eagle 34T DM / Steel

CHAIN

SRAM SX Eagle

CASSETTE

SRAM PG1210 / 11-50T

BRAKES

SRAM DB8 4 Piston Disc

ROTOR

SRAM Centerline CL Rotors 200mm F&R

HANDLEBAR

Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 760mm
Syncros Comfort lock-on grips

H'STEM

Syncros AM2.0 / 6061 Alloy
31.8mm / 4° / 1 1/8"

SEATPOST

Syncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm

SEAT

Syncros Capilano

HEADSET

Acros / 1.8"
ZS66 OD74 / 12mm Adapter / integr. Cable

HUB (FRONT)

Formula CL-811 / 15x110mm

HUB (REAR)

Formula CL-148S / Boost 148x12mm

SPOKES

Stainless Black

RIMS

Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready

FRONT TIRE

Maxxis Rekon / 29x2.6" / 120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra

REAR TIRE

Maxxis Rekon / 29x2.6" / 120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra

LIGHTS

Syncros integrated rear fender light
Front Light Cable pre-installed

APPROX WEIGHT IN KG

26.1 (with tubes)

MAX. SYSTEM WEIGHT

128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
